H20 timber beam in multi-layer web Home>Service>Building formwork>H20 timber beam
|
|
Being an important component in different formwork systems, RIMMCA H20 Timber Beam provides you different solutions together with using steel products & plywood for different projects.
RIMMCA H20 Timber Beam maintains a superior quality, long durability and high loading capacity with 3-layer web and multi-layer web for your selections.
Advantages:
1. Enjoying No.1 Timber manufacturer in Asia with its capacity more than 1000,000 linear meters annually.
2. Flange produced by the spruce imported from north Europe, ensures the beam quality higher than normal wooden.
3. Produce according to EN1337:2202 standard, comply with international technical request.
4. Made of superior quality solid wood with friction-fitted finger-joints, smoothly surfaced and slightly chamfered.
5. Tested by SGS on its resistance.
2. Flange produced by the spruce imported from north Europe, ensures the beam quality higher than normal wooden.
3. Produce according to EN1337:2202 standard, comply with international technical request.
4. Made of superior quality solid wood with friction-fitted finger-joints, smoothly surfaced and slightly chamfered.
5. Tested by SGS on its resistance.
Technical Data
|
ITEM |
Working Capacity |
EN Request |
SGS Test Report |
|
maximum bending resistance |
5KN.M |
10.9KN.M |
16.2KN.M |
|
maximum shearing resistance |
11KN |
23.9KN |
30.8KN |
|
maximum bearing resistance |
22KN |
47.8KN |
53.2KN |
